Electrical Fittings

GROUNDING FITTINGS

GROUND ROD CLAMPS

STANDARD GROUND CLAMPS WITH STAINLESS STEEL HEX BOLTS APPLICATION:

Used to connect bare copper wire to copper ground rod or rebar

FEATURES:

Cast from high strength, highly conductive copper alloy Approved for direct burial in earth and concrete

STANDARD MATERIALS:

Copper alloy Hex bolt - Stainless steel

APPLICABLE THIRD PARTY STANDARDS:

UL 467 CSA C22.2 No. 41 E#325028

PRODUCT NOTES:

__________________________ __________________________ __________________________ PART NUMBER PIPE RANGE WIRE RANGE REBAR SIZE COPPER ROD RANGE UNIT QUANTITY WEIGHT LBS PER 100 GRC50SS 1/2" #10 - #2 3/8" 3/8" - 16 100 9 GRC58SS 1/2" & 5/8" #10 - #2 1/2" 3/8" - 16 50 10 GRC34SS 3/4" #10 - #2 5/8" 3/8" - 16 50 11 GRCU5075SS 1/2", 5/8", & 3/4" #10 - #1/0 - 3/8" - 16 50 9
