Electrical Fittings

CONDUIT BODIES

FORM 8

APPLICATION:

To provide access to conductors for pulling, slicing and maintenance Makes bends and easily changes direction for conduit systems Allows for branch connection runs Provides easy access to conductors for maintenance and system changes

FEATURES:

Flat back body suitable for mounting on surfaces for stable installation and more cubic inch capacity Rated for wet locations when used with gasket and cover Tapered threaded hubs - NPT

STANDARD MATERIALS:

Gray iron

STANDARD FINISH:

Electroplated

APPLICABLE THIRD PARTY STANDARDS:

UL 514A Fed. Spec. A-A-50563 CSA Standard C22.2 18.3-04 NEMA FB-1 E#325029

PRODUCT NOTES:

__________________________ PART NUMBER TRADE SIZE SIZE UNIT QUANTITY WEIGHT LBS PER 100 A B C C18 1/2" 6" 1 - 7/16" 5 111 C28 3/4" 6 - 11/16" 1 - 11/16" 1 - 5/8" 5 148 C38 1" 7 - 9/16" 2" 1 - 7/8" 4 198 C448 1 - 1/4" 8 - 13/16" 2 - 5/16" 2 - 1/4" 2 311 C58 1 - 1/2" 10 - 3/16" 2 - 11/16" 2 - 13/16" 2 442 C68 2" 12 - 5/16" 3 - 9/16" 3 - 13/16" 1 770 C78 2 - 1/2" 16 - 3/16" 4 - 9/16" 5 - 1/16" 1 1513 C88 3" 16 - 3/16" 4 - 9/16" 5 - 1/16" 1 1595 PART NUMBER TRADE SIZE SIZE UNIT QUANTITY WEIGHT LBS PER 100 A B C LB18 1/2" 5 - 1/8" 2 - 1/4" 1 - 7/16" 5 108 LB28 3/4" 5 - 13/16" 2 - 1/2" 1 - 13/16" 5 147 LB38 1" 6 - 9/16" 2 - 7/8" 1 - 7/8" 4 201 LB448 1 - 1/4" 7 - 3/4" 3 - 1/4" 2 - 1/4" 2 303 LB58 1 - 1/2" 9 - 1/6" 3 - 11/16" 2 - 13/16" 2 445 LB68 2" 11 - 1/16" 4 - 3/8" 3 - 13/16" 1 700 LB78 2 - 1/2" 14 - 1/4" 6 - 1/8" 5 - 1/16" 1 1383 LB888 3" 14 - 1/4" 6 - 3/16" 5 - 1/16" 1 1480 LB98 3 - 1/2" 16 - 7/8" 7 - 3/16" 6 - 5/16" 1 2361 LB108 4" 16 - 7/8" 7 - 1/4" 6 - 5/16" 1 2533

C CONDUIT BODIES LB CONDUIT BODIES
